Conrad Welding Supplies, located in Houston, USA, is a well-respected manufacturer and supplier of Incoloy 800H Welding Wire. This wire is specifically designed for high-temperature structural welding applications where both strength and resistance to oxidation are crucial. It’s perfect for joining Incoloy 800H and other similar heat-resistant alloys, performing reliably even under prolonged exposure to heat and stress. Manufactured in line with AWS A5.14 (ERNiCr-3) standards, Conrad’s Incoloy 800H wire guarantees excellent arc stability, minimal spatter, and top-notch weld integrity. It finds extensive use in industries like petrochemical, furnace, power generation, and heat treatment, where thermal stability and metallurgical durability are key.
Incoloy 800H MIG Welding Wire Dealer in Texas, DIN 1.4958 Incoloy 800H Mag Welding Wire Price in Texas, Stockist of Alloy Incoloy Flux Core Welding Wire in Houston , 800H Incoloy MIG Welding Wire Price List in Houston , Incoloy 800H Filler Metal Welding Wire Manufacturer in California, UNS N08810 Incoloy 800H Welding Wire Exporter in USA, Incoloy 800H Welding Wire Distributor in Houston , USA
| Specifications | : | ASTM B166 ASME SB166 |
| Dimensions | : | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 |
| Length | : | 100 mm TO 6000 mm |
| Diameter | : | 10 mm To 100 mm |
| Specialize | : | Filler Wire, Coil Wire |
Incoloy 800H Welding Wire is made up of about 30–35% nickel, 19–23% chromium, at least 39.5% iron, and a combination of up to 1% aluminum and titanium to boost oxidation resistance and strength. This alloy maintains excellent stability at high temperatures thanks to its controlled carbon content (0.05–0.10%) and grain size. It boasts a tensile strength of at least 600 MPa, yield strength of at least 275 MPa, and elongation of at least 30%. These characteristics make it ideal for welds that need to resist creep and stress rupture, especially in pressure-containing components that face long-term high heat and corrosive environments.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32T |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4959 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
Incoloy 800H Welding Wire Weight Chart, Incoloy 800H MIG Welding Wire in USA, Incoloy Alloy 800H Mag Welding Wire Supplier in Los Angeles , 800H Incoloy Flux Core Welding Wire in Texas, 800H Incoloy Flux Core Welding Wire Stockist, Incoloy UNS N08810 Filler Metal Welding Wire Size Chart, Largest Stockholder of Incoloy Alloy 800H Welding Wire Houston , Stock of Incoloy 800H MIG Welding Wire Size Chart
Conrad Welding Supplies is a leading manufacturer and supplier of high-quality Incoloy 800H Welding Wire in Houston , USA. We specialize in providing innovative welding solutions, supplying a variety of products, such as coated electrodes, welding electrodes, flux core wires, MIG and TIG welding wires, SAW flux, and filler wires. Our welding products are designed for strength, high performance, and reliability. With a keen emphasis on customer satisfaction, we deliver excellent service and have become a respected partner for all your welding needs.
Incoloy Alloy 800H Mag Welding Wire Stockist California, 800H Incoloy Flux Core Welding Wire Exporter in USA, DIN 1.4958 Incoloy 800H MIG Welding Wire Price in California, Grade 800H Incoloy Flux Core Welding Wire Dimensions, Incoloy 800H Filler Metal Welding Wire Supplier in Houston , Stockist of Incoloy 800H Welding Wire in Houston , Incoloy 800H TIG Welding Wire Price List in Houston
Incoloy 800H Welding Wire Supplier in Texas, Incoloy 800H Filler Metal Welding Wire Stockist in Los Angeles , Incoloy Alloy 800H Welding Wire Dealer in Houston , Incoloy 800H Welding Wire List Los Angeles , 800H Incoloy Flux Core Welding Wire Distributor in Texas, Incoloy 800H MIG Welding Wire Dimensions, Incoloy Alloy 800H TIG Welding Wire Supplier in Houston .
Incoloy 800H Welding Wire is widely utilized in petrochemical and refinery operations, especially in hydrocarbon cracking, reforming furnaces, superheaters, and reheater tubing systems where high-temperature oxidation and creep resistance are essential. It’s perfect for welding parts like heat exchangers, pressure vessels, boiler tubing, and reactor chambers in power generation and heat-treating equipment. In the nuclear and chemical processing industries, it’s used for both the fabrication and repair of structures that undergo prolonged thermal cycling. Its exceptional thermal strength and metallurgical durability make it a go-to choice for demanding applications.
We provide high-quality electrodes, filler wire, MIG and TIG welding wires to a wide range of industries, including oil and gas, food, marine, petrochemical, power generation, and aerospace.
Conrad Welding Supplies is a leading manufacturer, supplier and exporter of high-quality Coated Electrodes, Flux Core, MIG & TIG wires, SAW & Flux, Welding Wires, and Filler Wires, catering to various industries in Houston , USA
