Conrad Welding Supplies, located in Houston, USA, is a well-respected manufacturer and supplier of AWS Class ER308LSi MIG and TIG Filler Welding Wire, specifically crafted for welding 304 and 304L austenitic stainless steels. This wire boasts a low carbon content, which helps minimize the risk of carbide precipitation, and a higher silicon level that enhances arc stability and bead appearance. Renowned for its outstanding corrosion resistance, smooth weld finish, and minimal spatter, Conrad’s ER308LSi wire is perfect for a variety of industries, including food processing, pharmaceuticals, petrochemicals, and architectural fabrication.
AWS Class ER308LSi MIG Filler Metal Weight Chart, Stainless Steel ER308LSi MIG Filler Wire Supplier in Texas, AWS Class ER308LSi MIG Filler Wire Exporter in Los Angeles , AWS Class ER308LSi MIG Filler Wire Manufacturer in Texas, Alloy ER308LSi Welding MIG and TIG Filler Metal Texas, UNS S30888 MIG and TIG Filler Wire Size Chart, AWS Class ER308LSi MIG/TIG Filler Welding Wire Manufacturer in Houston , Stainless Steel ER308LSi MIG and TIG Filler Metal Size Chart
| Classification | AWS A5.9, ER308LSi |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Current | MIG-DCEP / TIG-DCEN |
| Diameters | .023”, .030”, .035”, .045”, 1/16”, 3/32”, 1/8” |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ER308LSi MIG & TIG Filler Metal Application & uses |
|
The ER308LSi filler wire is made up of about 19–21% chromium, 9–11% nickel, and ≤0.03% carbon, along with 0.65–1.2% silicon to improve fluidity. This alloy offers excellent corrosion resistance in mildly corrosive environments and maintains good mechanical properties, with typical tensile strength ranging from 75–85 ksi. The low carbon content helps reduce sensitization and intergranular corrosion, while the added silicon enhances wetting action, resulting in smoother and more uniform welds, especially in automated and high-speed welding applications.
| Class | UNS | Oxford Alloys | SANDVIK | BOHLER | UTP |
| ER308LSi | S30888 | Alloy 308LSi | EXATON 19.9.LSI | BOHLER THERMANIT JE – 308L | UTP A68 LC |
| C | Cr | Ni | Mo | Mn | Si | P | S | Cu |
| 0.03 | 19.5-22.0 | 9.0-11.0 | 0.75 | 1.0-2.5 | 0.65-1.00 | 0.03 | 0.03 | 0.75 |
| Tensile Strength (psi) | 86,000 psi (593 MPa) |
|---|---|
| Yield Strength (psi) | 57,000 psi (393 MPa) |
| Elongation (%) | 42% |
| Diameter | Process | Volt | Amps | |
| in | (mm) | |||
| .023 | (0.6) | GMAW | 14-19 | 30-85 |
| .030 | (0.8) | GMAW | 15-20 | 45-125 |
| .035 | (0.9) | GMAW | 16-22 | 60-150 |
| .045 | (1.14) | GMAW | 17-22 | 90-210 |
| 1/16” | (1.6) | GTAW | 12 | 80-150 |
| 3/32” | (2.4) | GTAW | 12 | 150-250 |
| 1/8” | (3.2) | GTAW | 12 | 200-375 |
Oxford Alloy ER308LSi MIG Filler Wire Dealer in Texas, MIG Filler Wire Stockist, ASME SFA A5.9 MIG Filler Wire Price in Texas, Stockist of AWS Class ER308LSi MIG and TIG Filler Metal Dealer in Houston , AWS A5.9 MIG Filler Wire Price List in Houston , ER308LSi MIG Filler Wire Manufacturer in California, Oxford Alloy ER308LSi TIG Filler Wire Distributor Exporter in USA, Alloy ER308LSi MIG Filler Metal Manufacturer in Houston .
Conrad Welding Supplies is a Top manufacturer and supplier of high-quality AWS Class ER308LSi MIG and TIG Filler Welding Wire in Houston , USA. Specializing in welding solutions, we provide a wide range of products, including coated electrodes, welding electrodes, flux core, MIG & TIG welding wires, SAW flux and filler wires. Known for our reliable delivery and superior customer service, We are committed to offering top-tier welding materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your welding needs.
Stainless Steel ER308LSi TIG Filler Wire Stockist Houston , TIG Filler Wire Exporter in USA, SS ER308LSi TIG Filler Wire Price in California, ASME SFA A5.9 TIG Filler Wire Dimensions, AWS A5.9 TIG Filler Wire Supplier in Houston , Stockist of ER308LSi TIG Filler Wire in Houston , Welding Steel Based ER308LSi MIG and TIG Filler Metal Price List in Houston , Stainless Steel ER308LSi TIG Filler Metal Texas, AWS/ASME 5.14 ER308LSi MIG & TIG Filler Metal Supplier in USA
Stainless Steel ER308LSi MIG and TIG Filler Metal Supplier in Texas, UNS S30888 MIG and TIG Stick Filler Metal Manufacturer in Los Angeles , Stainless Steel Industrial ER308LSi MIG / TIG Filler Metal Stockist in Houston , AWS Class ER308LSi MIG/TIG Filler Welding Wire Price List, Oxford Alloy ER308LSi TIG Filler Wire Distributor in California, Stainless Steel ER308LSi TIG Filler Wire Dimensions, ER308LSi TIG Filler Wire Supplier in Houston , BOHLER Thermanit JE - 308L MIG Filler Wire Exporter in USA
This wire is commonly used for welding tanks, pipes, kitchen equipment, architectural structures, dairy and brewery machinery, and pressure vessels made from 304/304L stainless steel. It’s also suitable for joining stainless steel to mild or low-alloy steels when an austenitic stainless steel filler metal is needed. ER308LSi performs exceptionally well in both MIG and TIG processes, delivering clean, visually appealing welds with excellent corrosion resistance and mechanical strength. It’s a top choice for fabricators aiming for high-quality, low-defect welds in demanding stainless steel applications.
We provide high-quality electrodes, filler wire, MIG and TIG welding wires to a wide range of industries, including oil and gas, food, marine, petrochemical, power generation, and aerospace.
Conrad Welding Supplies is a leading manufacturer, supplier and exporter of high-quality Coated Electrodes, Flux Core, MIG & TIG wires, SAW & Flux, Welding Wires, and Filler Wires, catering to various industries in Houston , USA
