Conrad Welding Supplies is a well-respected manufacturer and supplier of top-notch welding products, proudly based in Houston, USA. Renowned for their exceptional performance and reliability, Conrad focuses on providing welding solutions like the AWS Class ER316LSi MIG and TIG filler wires. With a commitment to precision engineering and rigorous quality control, Conrad guarantees that its products meet the high standards demanded by professional welders and various industrial applications. Catering to sectors such as petrochemical, food processing, and marine, Conrad Welding Supplies is dedicated to fast delivery, expert technical support, and outstanding customer service across the United States and beyond.
AWS Class ER316LSi MIG Filler Metal Weight Chart, Stainless Steel ER316LSi MIG Filler Wire Supplier in Texas, AWS Class ER316LSi MIG Filler Wire Exporter in Los Angeles , AWS Class ER316LSi MIG Filler Wire Manufacturer in Texas, Alloy ER316LSi Welding MIG and TIG Filler Metal Texas, UNS S31688 MIG and TIG Filler Wire Size Chart, AWS Class ER316LSi MIG/TIG Filler Welding Wire Manufacturer in Houston , Stainless Steel ER316LSi MIG and TIG Filler Metal Size Chart
| Classification | AWS A5.9, ER316LSi |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Current | MIG-DCEP / TIG-DCEN |
| Diameters | .023”, .030”, .035”, .045”, 1/16”, 3/32”, 1/8” |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ER316LSi MIG & TIG Filler Metal Application & uses |
|
The AWS Class ER316LSi MIG and TIG filler welding wire features a composition of 18-20% Chromium, 11-14% Nickel, 2-3% Molybdenum, and a maximum of 0.03% Carbon, along with added Silicon (0.65-1.00%) to enhance the appearance and fluidity of the weld bead. This blend significantly boosts corrosion resistance, particularly against chlorides. In terms of mechanical properties, it boasts a tensile strength of around 80,000 psi (550 MPa), a yield strength of about 55,000 psi (380 MPa), and a minimum elongation of 30%. Its excellent ductility, toughness, and crack resistance make it perfect for high-performance welding in challenging environments.
| Class | UNS | Oxford Alloys | SANDVIK | BOHLER | UTP |
| ER316LSi | S31688 | Alloy 316LSi | EXATON 19.12.3.LSI | BOHLER THERMAINT GE-316LSI | UTP A68 MOLC |
| C | Cr | Ni | Mo | Mn | Si | P | S |
| 0.03 | 18.0-20.0 | 11.0-14.0 | 2.0-3.0 | 1.0-2.5 | 0.65-1.0 | 0.03 | 0.03 |
| Yield, kpsi: | 64 |
| Tensile Strength, kpsi: | 90 |
| Elongation%, min: | 37 |
| Diameter | Process | Volt | Amps | |
| in | (mm) | |||
| .023 | (0.6) | GMAW | 14-19 | 30-85 |
| .030 | (0.8) | GMAW | 15-20 | 45-125 |
| .035 | (0.9) | GMAW | 16-22 | 60-150 |
| .045 | (1.14) | GMAW | 17-22 | 90-210 |
| 1/16” | (1.6) | GTAW | 12 | 80-150 |
| 3/32” | (2.4) | GTAW | 12 | 150-250 |
| 1/8” | (3.2) | GTAW | 12 | 200-375 |
Oxford Alloy ER316LSi MIG Filler Wire Dealer in Texas, MIG Filler Wire Stockist, ASME SFA A5.9 MIG Filler Wire Price in Texas, Stockist of AWS Class ER316LSi MIG and TIG Filler Metal Dealer in Houston , AWS A5.9 MIG Filler Wire Price List in Houston , ER316LSi MIG Filler Wire Manufacturer in California, Oxford Alloy ER316LSi TIG Filler Wire Distributor Exporter in USA, Alloy ER316LSi MIG Filler Metal Manufacturer in Houston , BOHLER THERMAINT 25/14 E-309LSI TIG Filler Wire Exporter in USA
Conrad Welding Supplies is a Top manufacturer and supplier of high-quality AWS Class ER316LSi MIG and TIG Filler Welding Wire in Houston , USA. Specializing in welding solutions, we provide a wide range of products, including coated electrodes, welding electrodes, flux core, MIG & TIG welding wires, SAW flux and filler wires. Known for our reliable delivery and superior customer service, We are committed to offering top-tier welding materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your welding needs.
Stainless Steel ER316LSi TIG Filler Wire Stockist Houston , TIG Filler Wire Exporter in USA, SS ER316LSi TIG Filler Wire Price in California, ASME SFA A5.9 TIG Filler Wire Dimensions, AWS A5.9 TIG Filler Wire Supplier in Houston , Stockist of ER316LSi TIG Filler Wire in Houston , Welding Steel Based ER316LSi MIG and TIG Filler Metal Price List in Houston , Stainless Steel ER316LSi TIG Filler Metal Texas, AWS/ASME 5.14 ER316LSi MIG & TIG Filler Metal Supplier in USA, BOHLER THERMAINT GE-316LSI TIG Filler Wire Manufacturer in Texas
Stainless Steel ER316LSi MIG and TIG Filler Metal Supplier in Texas, UNS S31688 MIG and TIG Stick Filler Metal Manufacturer in Los Angeles , Stainless Steel Industrial ER316LSi MIG / TIG Filler Metal Stockist in Houston , AWS Class ER316LSi MIG/TIG Filler Welding Wire Price List, Oxford Alloy ER316LSi TIG Filler Wire Distributor in California, Stainless Steel ER316LSi TIG Filler Wire Dimensions, ER316LSi TIG Filler Wire Supplier in Houston , BOHLER THERMAINT GE-316LSI MIG Filler Wire Exporter in USA
The AWS Class ER316LSi MIG and TIG filler welding wire is commonly used for welding austenitic stainless steels, especially grades 316 and 316L, in applications that demand outstanding corrosion resistance and strength. It’s particularly well-suited for industries like chemical processing, pharmaceuticals, pulp and paper, food and beverage, and marine fabrication. The added silicon enhances arc stability and weld pool control, making it ideal for both manual and automated welding processes. You’ll often find it in piping systems, tanks, heat exchangers, and other components that face corrosive or high-moisture conditions.
We provide high-quality electrodes, filler wire, MIG and TIG welding wires to a wide range of industries, including oil and gas, food, marine, petrochemical, power generation, and aerospace.
Conrad Welding Supplies is a leading manufacturer, supplier and exporter of high-quality Coated Electrodes, Flux Core, MIG & TIG wires, SAW & Flux, Welding Wires, and Filler Wires, catering to various industries in Houston , USA
